Elestar Pattern Grading and Marker System

Description

This is an intelligent pattern design system, its design is base on human habit, tools are easy to choose and use. It saves a lot of time for pattern automatical functions, like the automatical pattern, grading, automatic sleeve, patch etc. Make your job become easy and not easy to make mistake, after compare, use Elestar CAD system the working efficiency can improve 100%-200% compare with manual and 30%-40% more compare with other CAD systems.

MTM: make to measure, only input your measurement, you can get your pattern immediately and size grading if you want, any modification is allowed here,you are so easy and fast to get new pattern,but no need start the here, you are so easy and fast to get new pattern, but no need start the design from beginning.
Automatic to make sleeve, one piece sleeve, two pieces and other fashion sleeves;

Powerful template function, any often-used pattern, of the embroidery design, sewing line design etc, you are easy to make here and save to library, easy to take and use for next time, and size can me re-edit.

Powerful aptitude pen, only one pen inside have more than 20 functions, very easy to switch, only one pen you can finish one pattern, it saves a lot of time to choose other tools.

The file can be saved and make copy automatically, not easy to lost, also can save by password, good for security.

The software can be installed any hard disk and save anywhere as your convenience File save and lookup is easy, not like other CAD systems.
Lock pattern, it will avoid your mistake when editing other patterns.

Powerful zoom in and zoom out function, very easy to control, and anytime and anywhere can show what you want, the system also supplies shortcut key for all functions, very easy to select and change tools.

Professional dart, pleat, gathering, the spread of step you can finish your design; powerful modification function and relative-modification, only change one part, be changeable relative be changed automatically.

(Garment Grading)The Elestar grading system supply automatical and manual grading, quickly, convenient and accurate, the system also supply many tools easy to modify your pattern and, you can quickly to switch the pattern and grading module, the pattern in grading can be changed automatically when the design has been changed.·Five grading methods point grading, line grading, body grading, should grading and curve grading to suit for different style and different part;

• Point grading is similar to traditional way, for operator logic,b ut keep fast copy, flip, remove or reset grading etc, keep reslut with high percision; For the points with same grading in X or Y, you can grading for all these points at one time.
• Shadow function,t he original line can be keep agter you make modification, you are easy to compare or use again for new design;
• Length comparison for any lines, curve and gradingm, you can check also modify;
• Zoom in and zoom out in proportion, also shrinkage is here.
• For jacket, combine with several parts, you could grading for the whole first, then divide it part by part, all divided parts, keep the original grading, it is different with manual way need grading for every part, so diffcult and easy to confuse.
• The pattern finish, the seam allowance can become automatically, or you can manual to add the same seam allowanc for all lones at one time, more than 10 kinds seam allowance corner available for your design.
• All often-used functions be controlled by shortcut key, very easy to switch and use.
• Good compatibility with all kinds of digitizer, pattern scanner.

Garment Marker System

• Time limited auto nesting, auto and manual interractive nesting and manual nesting are available for different style.
• Shrinkage is there,y ou can setup only for some pattern or fabric.
• Quick markers for costing.
• Rotate, filp, move, overlap are easy to control by the keyboard and mouse
• Automatic depart marker with different material or colors
• Strip and grid marker also available here, a ny kinds of grid you can setup and show on the screen,y ou can appoint the point to match the strip easily and exactly
• Quick modification of existing marker to create new one,t he pattern changed,t he marker can be changed in association
• The pattern can make little overlap and rotate, a lso pattern can be split to try to save more fabric.
• The marker can be rotate 180 degree or copy and embed nesting.
• Can output 1:1 or any proportion marker(Mini Marker)

Garment File Format Converter
Well compatibility with all standard files of DXF, AAMA, GERBER, LECTRA.

• Import DXF、AAMA format document exported from other CAD system.
• Import Gerber TMP or MOD format document.
• Import Lectra IBA format document.
• Import GBR format document.
• Import other kinds of format document, export as WDS、DXF、AAMA、PLT format.
• Elestar document exchange system can exchange files from many other CAD system.
